NightVision 21.5" LED Light Bar
$199.00
DESCRIPTION
SEE FURTHER. DRIVE EASY.
Need more light than your factory high beams? That's exactly what the NightVision 21.5" light bar is built for. Twenty 5W Osram LEDs throw a genuine 5,000 lumens down the road and push usable light out to around 487m, so you pick up corners, roos and washouts well before they're a problem.
Cheap bars flood the market for a reason — they look bright in the driveway, then the housing fills with water, the output drops off, and they're cactus inside a season. This one's sealed to IP68 and IP69K (dust-tight and rated for high-pressure, high-temp wash-downs), runs anywhere from 9–30V, and is rated to keep working from −40°C right up to 80°C. Built to keep going, not just to look good on the shelf.
MOUNTING
- Bolts to a bull bar, sits in the grille, or mounts to bodywork — wherever suits your setup
- Can be wired straight into the headlight loom. Most new cars with CAN bus will need relays and plug-and-play adaptors, available separately.
BUILT THE RIGHT WAY
- 20× 5W Osram LEDs — 5,000lm of real, usable output
- Sealed to IP68 & IP69K — dust-tight and pressure-wash safe
- Wide 9–30V range; rated to operate from −40°C to 80°C
- 5700K colour — a clean, daylight-white beam that's easy on the eyes
- Slim 557.6mm bar that tucks in without dominating the front end
SPECIFICATIONS
| Dimensions (L×W×H) | 557.6 × 48.7 × 46 mm |
| LED type | 20× 5W Osram LED |
| Effective lumens | 5,000LM ±500 @13.2V DC |
| Power draw | 76.56W ±7.92 @13.2V DC |
| Current draw | 5.8A ±0.6 @13.2V DC |
| Colour temperature | 5700K ±500 |
| Operating voltage | 9–30V DC |
| IP rating | IP68 & IP69K |
| Operating temperature | −40°C to 80°C |
| Storage temperature | −40°C to 60°C |
NIGHTVISION RANGE
| LED Power | 1 LUX Distance | Lumens | |
| NV-7 | 120W | 1480m | 14,440 |
| NV-9 | 165W | 1786m | 20,756 |
| NV-21 | 100W | 487m | 5,000 |
7" & 9" figures shown per pair; 21" per light.
